InsertingaMicroSDcard
1 2
D13245-1
Withthecardreader’scoveropen:
1.Insertthecardwiththecontactsfacingdown.
2.GentlypresstheMicroSDcardallthewayinto
thecardreaderslot.
3.Fullyclosethecardreadercover.
Important:Whenclosingthecoverensurethatit
isfullypushedinandsealedallthewayaround
theedge,thiswillprovidetheweatherproofseal.
RemovingaMicroSDcard
1 2
D13246-1
1.OndisplayproductsselectEjectSDCardfrom
theShortcutspage.
2.Openthecardreader’scover.
3.PinchtheprotrudingedgeoftheMicroSDcard
betweenyourindexngerandthumbandpullthe
cardclearofthecardreaderslot.
4.Fullyclosethecardreadercover.
Important:Whenclosingthecoverensurethatit
isfullypushedinandsealedallthewayaround
theedge,thiswillprovidetheweatherproofseal.
7.11Learningresources
Raymarinehasproducedarangeoflearning
resourcestohelpyougetthemostoutofyour
products.
