Plus Series Fishfinders
Placing a Waypoint
➤ To place a waypoint using the Waypoint List:
1. Press MARKS, followed by the WAYPOINT LIST soft key. The Waypoint List
and associated soft keys are displayed.
u
2. Press the MAKE NEW WAYPOINT soft key.
The waypoint is placed at the current vessel position, or if not available, the
cursor position. It is added to the Waypoint List and named with the next
available number.
To return to the default soft key display, press ENTER or CLEAR three times.
➤ To GOTO a cursor waypoint see
Going To an Individual Target Point
on
page 5-33.
➤ To ERASE a cursor waypoint see
Erasing a Waypoint
on page 5-15.
MARKS
WAYPOINT
LIST
GOTO
WAYPOINT
EDIT
WAYPOINT
MAKE NEW
WAYPOINT
WAYPOINT
TRANSFER
D4262-2
WAYPOINT LIST
SYMBOL NAME
WAYPOINT 001
WAYPOINT 002
WAYPOINT 003
WAYPOINT 004
WAYPOINT 005
50°21^966N
001°20^368W
POSITION
BRG _186°
RNG _21.0nm
TEMP
---°
C
DEPTH
---
m
DATE
--/--/--
TIME
--:--:--
MAKE NEW
WAYPOINT
