Chapter 1: Overview 1-1
Introduction
Chapter 1: Overview
1.1 Introduction
This handbook describes the following hsb
2
(High Speed Bus) Plus Series
Fishfinder displays:
Raymarine
hsb
2
Plus Series Fishfinders use the latest processor and sonar
technology for accurate performance and echo detection. Units feature 7" or
10.4" daylight viewable monochrome or color LCD displays and the
Raychart (RC) models include a full C-Map NT/NT+ Chartplotter. With up to
600 watts output power and dual frequency operation,
hsb
2
Plus Series
Fishfinders provide performance from 1 up to 3000 ft. In fact, the L1250 Plus
and L1250RC Plus units offer 1000 watts power and a depth range up to 5000
ft.
Use the High Speed Bus (
hsb
2
), SeaTalk and NMEA interfaces to provide an
integrated system with additional devices, such as Pathfinder Plus Radar,
Raymarine Autopilot and Raystar Wide Area Augmentation System (WAAS)
GPS products.
Connecting an
hsb
2
Series Plus Fishfinder to an hsb
2
Series Pathfinder Plus
Radar and to an
hsb
2
Series Plus Chartplotter enables fishfinder, radar, and
chart data to be displayed on all three units. Similarly, chart data can be
repeated on a fishfinder-only device from any via
hsb
2
from any other hsb
2
device with chart capabilities.
This handbook describes the display unit controls and details both fishfinder
and chart operations. Controls that are specific to either fishfinder or
chartplotter are described in fishfinder or chart sections/chapters.
Note: Many illustrations in this handbook show example screens. The screen
you see on your display depends on your system configuration and set up op-
tions, so it may differ from the illustration.
Fishfinder Display Type Display Size Chartplotter
L755RC Plus Monochrome LCD 7 inch Yes
L760 Plus
L760RC Plus
Color LCD
Color LCD
7 inch
7 inch
No
Yes
L1250 Plus
L1250RC Plus
Color LCD
Color LCD
10.4 inch
10.4 inch
No
Yes
