Chapter 2: Installation 2-1
Introduction
Chapter 2: Installation
2.1 Introduction
This chapter provides installation instructions for the hsb
2
Plus Series
Fishfinders. Simple systems such as that in Figure 2-1 below, or integrated
systems such as that in Figure 2-2 are explained (see Section 2.7). Details for
mounting the
hsb
2
Plus Series LCD Display and connecting the equipment are
included.
Figure 2-1: Typical Fishfinder System
NMEA
SeaTalk
Fishfinder Display
Distribution Panel
12/24V Supply
12V Supply
12V Supply
Junction
Box
GPS
Compass
Transducer
D5441-3
