5-10
hsb
2
Plus Series Fishfinders
Placing a Waypoint
2. Press the MAKE NEW WAYPOINT soft key followed by the LAT/LONG soft
key; the WPT POSITION (LAT/LONG) screen is displayed, with it’s associated
soft keys. The waypoint is placed at the current vessel position, or if not
available, the cursor position.
3. You can use the soft keys to edit the waypoint position as described in Edit-
ing the Waypoint Details on page 5-13.
It is added to the Waypoint List and named with the next available number.
To return to the default soft key display, press ENTER or CLEAR twice.
➤ To place a waypoint as Loran TDs using the Waypoint List:
1. Press MARK, followed by the WAYPOINT LIST soft key; the Waypoint List
and associated soft keys are displayed.
2. Press the MAKE NEW WAYPOINT, the waypoint is placed at the current ves-
sel position, or if not available, the cursor position. To change the position
press the LORAN TDs soft key; the WPT POSITION (LORAN TDs) screen is dis-
played, with it’s associated soft key:
GOTO
WAYPOINT
EDIT
WAYPOINT
MAKE NEW
WAYPOINT
WAYPOINT
TRANSFER
D4262-2
WAYPOINT LIST
SYMBOL NAME
WAYPOINT 001
WAYPOINT 002
WAYPOINT 003
WAYPOINT 004
WAYPOINT 005
50°21^966N
001°20^368W
POSITION
BRG _186°
RNG _21.0nm
TEMP
---°
C
DEPTH
---
m
DATE
--/--/--
TIME
--:--:--
MAKE NEW
WAYPOINT
