Chapter 1: Overview 1-3
Introduction
Appendix C defines the chart features shown on the chart display.
Appendix D defines the SeaTalk and NMEA data that is transferred on
integrated systems.
A List of Abbreviations, Index and warranty information are included at the
end of the handbook.
A summary of the fishfinder and chartplotter controls are provided on the
Quick Reference Cards supplied with your system.
Terminology
The following terminology is used to describe the various display unit
configurations:
Master A unit capable of sourcing specific data such as
fishfinder, chart, or radar data.
Repeater A unit capable of displaying data, such as radar,
from the High Speed Bus.
Fishfinder Display Unit providing Fishfinder Master and Radar
Repeater functionality. The L755RC, L760RC,
and L1250RC Plus displays also provide Chart
Master functionality.
Radar Display Unit providing Radar Master, Fishfinder
Repeater and Chart Reader functionality.
Chart Display Unit providing Chart Master, Fishfinder
Repeater and Radar Repeater functionality.
Combined Display Unit providing both Fishfinder and Chart or
Radar and Radar Repeater functionality.
Integrated System Additional instruments are connected via
hsb
2
,
SeaTalk or NMEA interfaces.
hsb
2
High Speed Bus- links up to ten compatible dis-
play units. For full display and control between
hsb
2
Plus Series display units, the units must be
connected via
hsb
2
and SeaTalk.
