Chapter 1: Overview 1-7
Operating Modes
Half -Screen Window Options
The following information, if available on your system, can be shown:
• Chart display (when in Fishfinder or Radar mode)
Fishfinder display (when in Chart mode):
Radar display (when in Chart mode):
If data is available, either as a function of the combined display unit or via
the
hsb
2
link, it can be displayed.
• Depth/temp graph (Fishfinder mode): This shows a plot water tempera-
ture and depth against time.
• Data (Fishfinder mode): This option splits the fishfinder vertically. The
left hand window displays data boxes; there are three different sets of data
(A, B and C) that you can select for display.
• CDI: This gives the Course Deviation Indicator graphical display, with
data relating to the target waypoint.
• BDI: This gives the Bearing and Distance Indicator graphical display, with
data relating to the target waypoint.
• Nav Data (Chart mode): This shows sixteen data boxes, providing navi-
gational data in the units specified in your set up. Note that up to 6 of these
data boxes are also available as a user-selectable group (see Section 7.3).
For details on the radar, refer to the Owner’s Handbook supplied with your
radar.
Note: MARPA functionality is available on the fishfinder display if you have
an integrated system with a Pathfinder radar master display that includes
MARPA as a primary function.
Details on selecting windows are given in Chapter 3.
Table 1-1: Window Options for Combined/Integrated Systems
Full-screen
mode
Half-screen Window Options -
Fishfinder/Chart Display only
Half-screen Window Options -
Fish/Chart + Radar Displays
Fishfinder Mode Depth/temp, Chart, CDI, BDI, or Data Depth/temp, Chart or CDI, BDI
Chart Mode CDI, BDI, Nav Data or Fishfinder CDI, BDI, Nav Data, Fishfinder or
Radar
Radar Mode Not Available CDI, BDI, Chart or Nav Data
Data Log Mode Half-screen Windows not available Windows not available
