D-2 hsb
2
Plus Series Fishfinders
SeaTalk and
NMEA Data
The hsb
2
Plus Series display unit transmits the following data, if available,
on SeaTalk:
1
When available, NMEA OUT data is transmitted from a combined Fishfinder/Chartplotter display or
from a Fishfinder-only unit if connected to a Chart display via
hsb
2
.
2
Fishfinder data.
3
Bridged from NMEA if selected in the System Set Up menu.
4
When available, NMEA OUT data is transmitted from a Fishfinder display only if connected to a Radar
display via
hsb
2
.
Data Output SeaTalk NMEA Out
Position (LAT/LON) ✔ GGA, GLL, RMC
1
, RMA
Position (Loran C TD’s) ✔ RMA
Speed Over Ground and
Course Over Ground
✔ RMC, VTG
1
,
, RMA
Waypoint Data ✔ RMB, APB, BWC, BWR
1
Depth ✔ DBT, DPT
2
Apparent Wind Angle and Speed ✔ —
Boat Speed Through Water ✔ VHW
2
Total Log and Trip Log ✔ VLW
2
Water Temperature ✔ MTW
2
Heading ✔ VHW
2,3
Magnetic Variation ✔ RMA, RMC
Time ✔ ZDA
Date ✔ ZDA
MOB data ✔ —
Cursor Range & Bearing ✔ RSD
4
EBL/VRM Data — RSD
4
Heading mode — RSD
4
Radar display range ✔ RSD
4
Radar Tracked targets — TTM
4
Waypoint/Route Transfer — WPL, RTE
Global Alarm
Waypoint Arrival Alarm
SeaTalk —
APB, RMB
