Chapter 2: Installation 2-23
SeaTalk and NMEA
In
Figure 2-13: Integrated System with Repeater Displays and SeaTalk Instruments
12/24V
Supply
12/24V
Supply
12/24V Supply
12/24V Supply
HSB HSB
12/24V Supply
12/24V Supply
SeaTalk
SeaTalk
SeaTalk
SeaTalk SeaTalk
GPS
hsb
2
Series Radarhsb
2
Series Chartplotterhsb
2
Series Fishfinder
D5578-2
Scanner
SeaTalk
Course Computer
Distribution Panel
SeaTalk
Transducer
