3-8
hsb
2
Plus Series Fishfinders
Changing the
Brightness & Color
Settings (Color LCD)
➤ To change the background color:
1. Press the MULTI key to display the soft key controls, then press COLOR SET-
TINGS.
2. Press the BGROUND COLOR soft key. The background color soft keys are
displayed below a pallet of available colors. The selected color is high-
lighted.
3. Press the left or right BACKGROUND COLOR soft key until the required color
is highlighted.
The fishfinder display changes, so you can see the effect as you change the
background color.
4. Press ENTER or CLEAR twice to return to the MULTI soft keys.
Selecting the Color Threshold
You use the color threshold control to determine the minimum echo strength
that is displayed. Each range of echo strengths is displayed in a color as shown
in the color bar; you select the minimum strength that is displayed by blanking
echo colors below the required minimum.
If you blank a color, the corresponding echoes are displayed in the background
color. You can remove up to six colors, but you cannot remove the strongest
color.
The color threshold you select is used on all the fishfinder windows (scrolling
bottom, Zoom, Bottom Lock and A-Scope).
➤ To change the color threshold:
1. Press the MULTI key to display the soft key controls, then press COLOR SET-
TINGS.
2. Press the COLOR THRESH soft key. The color threshold soft keys are dis-
played below color indicator showing the available echo colors.
The weakest color is at the bottom of the indicator, the strongest color at the
top; you can remove colors from the bottom up.
3. Press the left or right ADJUST COLOR THRESHOLD soft key to change the
color threshold.
Pressing the left key removes out the next color up, it increases the mini-
mum strength displayed.
Pressing the right key displays the next color down, it decreases the mini-
mum strength displayed.
4. Press ENTER or CLEAR twice to return to the MULTI soft keys.
MULTI
COLOR
SETTINGS
B'GROUND
COLOR
MULTI
COLOR
SETTINGS
COLOR
THRESH
