Chapter 3: Getting Started & Adjusting the Display 3-27
Customizing the
Screen Presentation
Options
At any time, you can switch the group of data boxes on or off using the SCREEN
soft key. When first installed, the boxes are all OFF. When the display unit is
switched off and on again, the data boxes return to their last-used states (ON or
OFF) and positions.
Note: The SCREEN soft key does not control the sixteen data boxes that can be
displayed in the half-screen window.
➤ To switch the group of data boxes on or off:
1. Press the SCREEN default soft key.
2. Press the DATABOXES soft key to toggle the setting from ON to OFF or from
OFF to ON.
To return to the default soft key display, press ENTER.
If you turn the data boxes on and none are displayed, you need to select the
ones you require using the system set up menu, as described in Section 7.3.
➤ To move any data box:
1. Use the trackpad to position the cursor over the box until the letters BOX are
displayed.
2. Press ENTER to take control of the box, use the trackpad to move it to the
required position, and press ENTER again.
Custom Options - Chart Mode
When chart details have been customized in the Chart Set Up menu (as
described in Section 7.5) the SCREEN soft key can be used to switch the custom
chart options off or on:
When set to ON, all chart options set to CUSTOM in the Customize Chart menu
are displayed; when set to OFF, options set to CUSTOM are not shown.
The factory default for custom chart options is ON.
➤ To switch the customized options on or off:
1. Press the SCREEN default soft key.
2. Press the CUSTOM soft key to toggle the setting from OFF to ON or from ON
to OFF.
To return to the default soft key display, press ENTER.
SCREEN
CRSR BOX
OFF ON
CHRT GRID
OFF ON
DATABOXES
OFF ON
BOX
SCREEN
CRSR BOX
OFF ON
CHRT GRID
OFF ON
DATABOXES
OFF ON
CUSTOM
OFF ON
