18 Raypak, Inc.
HTC# 059105-00D

--------SETTINGS----
Season Winter
SystemTarget140
o
F
<SystemSettings>
<Maintenance>
<SystemStartup>
BACK▲▼SELECT
--AREYOUSURE?--
No
Yes
BACK▲▼SAVE
---SENSORTYPE---
Reset
o
F
Reset
o
C
4-20mAEMS
BACK▲▼SAVE
-SWITCHSETPOINT-
150
o
F
[ ]
BACK▲▼SAVE
---SWITCHDIFF---
10
o
F
[ ]
BACK▲▼SAVE
---SWITCHDELAY---
0.5Hour
[ ]
BACK▲▼SAVE
HEAVYLOAD
-SEQUENCE#2GROUP-
No
Yes
BACK▲▼SAVE
CONDENSING
----BOILERTYPE----
Modulating
Staging
BACK▲▼SAVE
CONDENSING
--BOILERNUMBER--
2
[ ]
BACK▲▼SAVE
CONDENSING
-MODULATINGMODE-
Normal
Parallel
BACK▲▼SAVE
NON-CONDENSING
----BOILERTYPE----
Modulating
Staging
BACK▲▼SAVE
PROVE/DHWSHARING
Prove
DHWPriority
DHWNoPriority
NoPriority(Summer)
BACK▲▼SAVE
-DHWSETPOINT-
180
o
F
[ ]
BACK▲▼SAVE
-SETBCK/SHUTDOWN-
Shutdown/Disable
Tstat/Enable
Setback
BACK▲▼SAVE





CONDENSING
--OUTPUTATYPE--
4-20mA
0-10volt
1-10vCustom
BACK▲▼SAVE
---BOILERTYPE---
Modulation
Staging
Hybrid
BACK▲▼SAVE
-EMS4maSETPOINT-
70
o
F
[ ]
BACK▲▼SAVE
-EMS20maSETPOINT-
220
o
F
[ ]
BACK▲▼SAVE


---BOOSTMODE---
30Minutes
Disable
BACK▲▼SAVE
---SENSORFAULT---
AllOff
AllOn
BACK▲▼SAVE
NON-CONDENSING
--BOILERNUMBER--
1
[ 
]
BACK▲▼SAVE
CONDENSING
--OUTPUTBTYPE--
4-20mA
0-10volt
1-10vCustom
BACK▲▼SAVE
NON-CONDENSING
--OUTPUTCTYPE--
4-20mA
0-10volt
1-10vCustom
BACK▲▼SAVE
NON-CONDENSING
-MODULATINGMODE-
Normal
Parallel
BACK▲▼SAVE
Yes

---BACNETMODE---
Disable
Enable
BACK▲▼SAVE









  





