44 Raypak, Inc.
HTC# 059105-00D
Model Device Object MODEL
Serial Number Device Object SNUMBER
Version Device Object VERSION
Operation Mode 100 MULTISTATE-VALUE OPMODE 1 6
1=Modulation Reset,2= Staging Reset,3=Hybrid Reset, 4=Modulation Setpoint,
5=Staging Setpoint, 6=Hybrid EMS
Outdoor Temperature 200 ANALOG-VALUE ODTEMP Degree F 32000=OPEN,3201=SHORT
System Temperature 300 ANALOG-VALUE SYSSEN Degree F 32000=OPEN,3201=SHORT
Output Status 400 ANALOG-VALUE OPTSTAT 0 0x1FFFF
Each Bit represents one of the possible 16 relays. Bit 0 represents Relay1, Bit 16
represents Relay16. 0 = Relay OFF, 1 = Relay ON
Control Status 500 MULTISTATE-VALUE CSTAT 1 13
1=SHUTDOWN,2=NO TSTAT CALL,3=PROVE FAILURE,4=SHUTDOWN
BY EMS,5=WAITING FOR PROVE,6=SENSOR FAULT,7=LAST STAGE
HOLD,8=DHW CALL,9=SUMMER,10=BOOST MODE,11=SYSTEM
RUNON,12=SETBACK MODE,13=OUTDOOR CUTOFF
Season 600 MULTISTATE-VALUE SEA 1 2 1= Winter, 2= Summer
Reset Ratio 700 MULTISTATE-VALUE RR 1 11
1 =1.00 OD = 4.00 Sys,2 =1.00 OD = 3.00 Sys,3 =1.00 OD = 2.00 Sys,4 =1.00
OD = 1.50 Sys, 5 =1.00 OD = 1.25 Sys,6 =1.00 OD = 1.00 Sys,,7 =1.25 OD =
1.00 Sys,8 =1.50 OD = 1.00 Sys,9 =2.00 OD = 1.00 Sys,10 =3.00 OD = 1.00
Sys,11 = 4.00 OD = 1.00 Sys
Offset 800 ANALOG-VALUE OFF Degree F -50 50 Integer Values Only (-1,0,1,2…)
Outdoor Cutoff 900 ANALOG-VALUE CO Degree F 19 101 Integer Values Only (19,20,21…)
Min Water Temp 1000 ANALOG-VALUE MINW Degree F 50 180 Integer Values Only (50,51,52…)
Max Water Temp 1100 ANALOG-VALUE MAXW Degree F 70 220 Integer Values Only (70,71,72…)
Setback 1200 ANALOG-VALUE SB Degree F 0 75 Integer Values Only (0,1,2…)
Purge Delay 1300 ANALOG-VALUE PDLY Minutes .1 10 .1 thru .9 after Integer Values Only (1,2,3…)
System Runon 1400 ANALOG-VALUE RUNON Minutes 0 360 Integer Values Only (0,1,2…)
Rotation Time 1500 ANALOG-VALUE RTTIME Hours 1 1440 Hours since last rotation Integer Values Only (1,2,3…)
Standby Time 1600 ANALOG-VALUE STBYDLY Minutes 1 60 Integer Values Only (1,2,3…)
Last Stage Hold 1700 ANALOG-VALUE LSTHOLD Degree F 0 30 Integer Values Only (0,1,2…)
Con Lead Stage 1800 MULTISTATE-VALUE CLEAD 1 16 Represent the current lead boiler for the condensing group
Non-Con Lead Stage 1900 MULTISTATE-VALUE NCLEAD 1 16 Represent the current lead boiler for the non-condensing group
Reaction Time 2000 ANALOG-VALUE RETIME Minutes 1 10 Integer Values Only (1,2,3…)
Min Run Time 2100 ANALOG-VALUE MINRUN Minutes 1 60 Integer Values Only (1,2,3…)
Gain 2200 MULTISTATE-VALUE GAIN 1 10
Lag Delay 2300 ANALOG-VALUE LAGDLY Minutes 0 60 Integer Values Only (0,1,2…)
Soft off 2400 ANALOG-VALUE SOFF Seconds 0 60 Integer Values Only (0,1,2…)
Set Time 2500 ANALOG-VALUE PTIME Minutes 1 1440 Time since midnight Integer Values Only (1,2,3…)
Day Schedule 2600 ANALOG-VALUE DSCHED Minutes 1 1440 Time since midnight Integer Values Only (1,2,3…)
Night Schedule 2700 ANALOG-VALUE NSCHED Minutes 1 1440 Time since midnight Integer Values Only (1,2,3…)
