SENSOR SYNC
NOTE: Using genlock requires a DSMC2 Base Expander, DSMC2 V-Lock I/O Expander, DSMC2 Jetpack Expander,
DSMC2 Jetpack-SDI Expander, or DSMC2 REDVOLT Expander. For more information, go to to "Input/Output
Connectors" on page215.
NOTE: HDRX
®
is not available when Genlock Sensor Sync is enabled.
Sensor Sync is achieved when a genlock signal is provided that is compatible with the current monitor output
frequency, project time base, and recording frame rate. While operating in Sensor Sync, sensor timing is locked to the
genlock signal.
Sensor Sync requires the following synchronized settings:
Setting Menu Location Path
Genlock signal frequency N/A; external genlock device
HD-SDI monitor output frequency
Menu > Settings > Display > Monitor Control
Project Time Base
Menu > Settings > Project > Frame Rate
Recording Frame Rate
Menu > Settings > Project > Frame Rate
