Getting Started
4-2 SmartEdge 100 Router Hardware Guide
Table 4-1 lists the tools that you need to install the SmartEdge 100 hardware.
Safety and ESD Considerations
To ensure a safe and trouble-free installation, follow these recommendations:
• Site and Installation Considerations
• General Safety
• Electrical Precautions
• Reducing the Risk of ESD Damage
Site and Installation Considerations
To ensure a safe and trouble-free site and installation, follow these guidelines:
• Maximum recommended operating temperature
The maximum recommended long-term operating temperature for the SmartEdge 100 system is 104°F
(40°C). Determine a suitable operating environment based on this recommendation.
• Elevated operating ambient temperature
If the chassis is installed in a closed or multiunit rack, the operating temperature of the rack environment
can be greater than the ambient temperature of the room. Remember this condition when you install the
chassis.
• Reduced airflow
Install the SmartEdge 100 chassis in the rack so that the airflow required for the safe operation of the
equipment is not compromised. Air inflow is at the front of the chassis; air outflow is at the rear of the
chassis.
• Mechanical loading
Ensure you do not create a potentially hazardous condition from uneven loading when you select the
mounting position in the rack for the SmartEdge 100 chassis.
Table 4-1 Tools Needed for SmartEdge 100 Installation
Tool Purpose
#1 Phillips screwdriver Install MICs.
#2 Phillips screwdriver Attach the mounting brackets and cable management brackets to the chassis.
#2 or #3 Phillips screwdriver
1
1. Depending on the screws that you use to install the chassis in a rack, a #3 Phillips screwdriver might be more appropriate than the
#2 screwdriver.
Install the chassis in the rack.
3/32-inch slotted screwdriver Install DC power cables.
Cable crimping tool Secure barrel, open, or ring lugs to the chassis ground cable; must be compatible
with FCI YA4C series of compression lugs (Y2MR or equivalent).
