Planning the Site and Installation
3-2 SmartEdge 100 Router Hardware Guide
Select the Installation Site
Select the installation site for the SmartEdge 100 router, considering maintenance, electrical, and
ventilation requirements. Also, consider current and future cabling requirements. The following topics
provide information to assist you with site selection:
• Agency Compliance Information
• Electrical Specifications
• Environmental Requirements
• Physical Specifications
Agency Compliance Information
Table 3-1 lists the agency compliance standards to which the SmartEdge 100 hardware is designed to meet.
Electrical Specifications
Table 3-2 lists the electrical specifications for the AC version of the SmartEdge 100 chassis.
Table 3-1 Agency Compliance Standards
Product Safety Emissions Immunity
UL 60950
CSA 22.2 No. 60950
IEC60950
EN60950
AS/NZS 3260
FCC part 15, Class A
ETSI EN300 386-2
CISPR 22, Class A
ICES-003, Class A
VCCI, Class A
EN55022, Class A
EN61000-3-2
EN61000-3-3
AS/NZS 3548, Class A
EN61000-3-3
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
EN61000-4-8
EN61000-4-11
EN300 386-2
Table 3-2 AC Electrical Specifications
Requirement Value
Voltage, nominal
Voltage, maximum
90 to 132 VAC, 47 to 63 Hz
170 to 264 VAC, 47 to 63 Hz
Power consumption, nominal
Power consumption, maximum
205 watts
300 watts
Current draw, nominal
Current draw, maximum
2.3A @110 VAC
3.8A @90 VAC
