Redback Networks SmartEdge 100 User Manual

FE and GE MIC and Native Port Cables
Cables and Pin Assignments A-5
Copper FE Straight Cable
A copper FE straight cable is a shielded and grounded cable; both ends are terminated in standard, RJ-45
eight-pin modular plugs. Table A-8 lists the pin assignments, which are for both ends of the cable.
3Tx (+) 1 –
4 – – Termination network
5 – – Termination network
6Tx (–) 2 –
7 – – Termination network
8 – – Termination network
Table A-8 Copper Ethernet Straight Cable Pin Assignments
Pin Signal Name Notes
1Rx (+) –
2Rx (–) –
3Tx (+) –
4 – Termination network
5 – Termination network
6Tx (–) –
7 – Termination network
8 – Termination network
Table A-7 Copper Ethernet Crossover Cable Pin Assignments (continued)
One End Other End
Pin Signal Name Pin Notes
