Regency
®
Model 4720 Control/Communicator Installation Manual (P/N 150476, Rev. A) Revised 10/98
• Model 4150 External Control Module.
This module may be used for remote control of doors, timed control of lights and remote sensing of
temperature, humidity, fluid level, and air flow.
• Model 4160 Supervised Bell Module.
This module must be used when installing the Model 4720 for NFPA 72A.
• Model 4165 Transformer Housing for NFPA installations.
• Model 4175 Dual Phone Line Monitor With Ring Detector.
Used in applications where two (2) phone lines are required.
• Model 4180 Status Display Module.
(Serves as an interface to Long Range RF or Derived Channel.)
• Model 4184 Audible Watchdog Trouble Module.
Provides backup supervision of control and touchpads. Required for NFPA 72A.
• Model 4195 Auxiliary Power Supply and Battery Charger.
Provides an additional 2.5 A of power in addition to the built-in supply. Required for NFPA 72A.
• Model 4203 SlimLine Touchpad.
This touchpad is weather resistant for outside use. Used for arming, disarming, and Model 4150 Relay
Access.
• Model 4205 Weather resistant, SlimLine Door Access Touchpad.
• Model 4300 Card Reader.
• Model 4360 Desktop Adapter.
This angled back-base adapts the Model 4553 residential wall-mount touchpad to desktop use but does
not use the PLC interface.
• Model 4420 Door Access Module.
• Model 4660B/C (Commercial) and Model 4660R (Residential) Touchpads.
These 4-wire digital touchpads include a liquid crystal display (LCD) that shows the system status and
provides helpful messages for troubleshooting and programming.
• Model 5255 On-Site Printer. (Discontinued)
• Model 5260 Printer Interface. (Not investigated by UL.)
• Model 5520 EEPROM Programmer.
• Model 5530 Modem (allows downloading from the Model 5520 Desktop Programmer or from a
computer).
• Model 5540 Downloading Software.
Requires Model 5530 Modem and an IBM PC or compatible.
• Model 6712 6.5-A Rechargeable Battery.
• Model 7369 Two-Way Audio Listen-in Module.
2 Preconnection Requirements
2.1 Telephone Requirements
1. If requested by the telephone company, the following information must be provided before connecting
this device to the phone lines:
A. Manufacturer - ITI
B. Model Number - 4720
C. FCC Registration number - AC698R-69183-AL-R
D. Type of jack (to be installed by the telephone company) - RJ31X
Note: The telephone company must also be notified if this device is permanently disconnected.
2. This device may not be directly connected to coin telephone or party line services.
3. The telephone company under certain circumstances may temporarily discontinue services and/or make
changes in its facilities and services which may affect the operation of this device; however, the
telephone company is required to give adequate notice in writing of such changes or interruptions.
