16
Regency
®
Model 4720 Control/Communicator Installation Manual (P/N 150476, Rev. A) Revised 10/98
3.14 Model 4720 Terminal Strip Description
* Note 1: Terminal 4 (16 V) will be at 20 V under normal standby conditions (non-alarm).
* Note 2: Each device connected to Terminal 5 or 10 must be rated for the voltage ranges specified. The minimum
voltage occurs when AC power is off and the battery is discharging under load. The maximum voltage
occurs when AC power is on and the output is not loaded.
* Note 3: The total current drain of Terminal 5, Terminal 10, all touchpads, and all XBUS expansion devices, must
not exceed 1.35 A (see Table 4.1.1.0a).
* Note 4: See Section 3.3.1 for an explanation of PolySwitch protection.
UL note: Refer to wiring diagram on the unit for ratings/connections.
Terminal # Terminal Description Electrical Ratings
1 AC input 16.5 V
AC
, 60 Hz, 40 VA
2 AC input 16.5 V
AC
, 60 Hz, 40 VA
3 Earth Ground
4 Siren Power
16 V
DC
unregulated (1-A load) max.
*1
5 Auxiliary (Bell) Power
10.2 V
DC
- 13.7 V
DC
, 1 A max.
*2 *3
(PolySwitch-protected to 1.1 A min. -
Revision L and later PCB revs.)
*4
(fused
1.5 A - earlier revisions)
6 Circuit Ground
7 External Speaker/Bell Output (Active Low) 500 mA max.
8 Internal (Touchpad) Speaker Output (Active Low)
9 Circuit Ground
10 Smoke Detector Power 11.2 V
DC
- 14 V
DC
, 150 mA max. *2 *3
11 Loop Power +12 V
DC
, 50 mA max. (current limited)
12 Loop Power +12 V
DC
, 50 mA max. (current limited)
13 Loop Power +12 V
DC
, 50 mA max. (current limited)
14 Loop Power +12 V
DC
, 50 mA max. (current limited)
15 Optional output for use with Model 4724 Control
Expander
16 Model 4203 Touchpad Pin 1
17 Model 4203 Touchpad Pin 2
18 Model 4203 Touchpad Pin 3
19 Touchpad Ground
20 Touchpad Power
21 Data Output to Touchpad
22 Data Input From Touchpad
23 Zone 1 Input
24 Zone 2 Input
25 Zone 3 Input
26 Zone 4 Input
27 Zone 5 Input
28 Zone 6 Input
29 Zone 7 Input
30 Zone 8 Input
31 Zone 9 Input
32 Zone 10 Input
33 Zone 11 Input
34 Zone 12 Input
35 Zone 13 Input
36 Zone 14 Input
37 Zone 15 Input
38 Zone 16 Input/Mechanical Key Input
39 Ground Start Output 100 mA Max. Active Low
40 Dialer Failed Output 100 mA Max. Active Low
41 Telco Tip
42 Telco Ring
43 House Tip
44 House Ring
45 Audio Output (Alarm and Alert Tones)(Active Low)
