Regency 4720 - SIA Reporting Format

72
Regency
®
Model 4720 Control/Communicator Installation Manual (P/N 150476, Rev. A) Revised 10/98
22 SIA Reporting Format
9000 Printer Code Status of 4720
Low battery 0
Battery restore 0
YT0
YR0
System battery low
Battery voltage back to normal
AC trouble 0
AC restore 0
AT0
AR0
AC house power off
AC house power back on
Phone line trouble 1
Phone trouble 2
Phone line restore 1
Phone line restore 2
LT1
LT2
LR1
LR2
Phone Line 1 not working
Phone Line 2 not working
Phone Line 1 back to normal
Phone Line 2 back to normal
Expansion trouble 0 ET0 Dialer trouble
Expansion trouble 1 ET1 Printer trouble
Expansion trouble 2 ET2 Zone Expander 1 trouble
Expansion trouble 3 ET3 Zone Expander 2 trouble
Expansion trouble 4 ET4 Intercom trouble
Expansion trouble 5 ET5 Auxiliary control (obs. Model 4150) trouble
Expansion trouble 6 ET6 Not used
Expansion trouble 7 ET7 Memory trouble
Expansion trouble 8 ET8 Control trouble
Expansion trouble 9 - 16 ET9 -
ET16
Not used
Expansion trouble 17 - 31 ET17 -
ET31
Touchpad 1 -15 trouble
Expansion restore 0 ER0 Dialer back to normal
Expansion restore 1 ER1 Printer back to normal
Expansion restore 2 ER2 Zone Expander 1 back to normal
Expansion restore 3 ER3 Zone Expander 2 back to normal
Expansion restore 4 ER4 Intercom (Model 4140) back to normal
Expansion restore 5 ER5 Auxiliary control (obs. Model 4150) back to
normal
Expansion restore 6 ER6 Not used
Expansion restore 7 ER7 EE memory back to normal
Expansion restore 8 - 16 ER8 -
ER16
Not used
Expansion restore 17 - 31 ER17 -
ER31
Touchpad 1 - 15 back to normal
Auto close CA0 System automatically armed
Auto open CO0 System automatically disarmed
Close ID 0 - 99 CL0 - 99 System armed by access Code 0 - 99
Force close ID 0 - 99 CW0-99 Forced armed by access Code 0 - 99
Supervisory close 0 CI0 Failed to open (still armed)
Supervisory open 0 OI0 Failed to close (still disarmed)
Close area 1 - 8 CG 1 - 8 Area 1 - 8 armed
Open area 1 - 8 OG 1 - 8 Area 1 - 8 disarmed
Open reset alarm ID 0-99 OR 0 - 99 Alarm reset by access Code 0 - 99
Door ID 0 - 99 DG 0 - 99 Door access granted Code 0 - 99
Door station 1 - 15 DS 1 - 15 Access granted at Door 1 - 15
Door left open station 1 - 15 DO 1 - 15 Door left open at Touchpad 1 -15
Door forced open station 1 -
15
DF 1 - 15 Door forced open at Touchpad 1 - 15
Auto test 0 RP0 Automatic dialer test
Manual test 0-99 RX0 - 99 System tested by Code 0 - 99
Data lost 0 RT1 Previous event could not be reported and the
information was lost
* Note: The 4720 sends “MA”; the Model 4724-2 and the Model 4734-2 send “QA”.
