Model 4720 Control/Communicator Installation Manual (P/N 150476, Rev. A) Revised 10/98
73
The Model 4720 is compatible with the following UL Listed receivers (the formats used for each receiver are
shown in parentheses):
Regency Model 9000 (SIA < FSK1, SK 4/2, Radionics BFSK)
Regency Model 8510/8520 (FSK, SK 4/2)
Radionics Model 6000/6500 (Radionics BFSK)
FBI Model CP220 (SK 4/2, Radionics BFSK)
Osbourne/Hoffman Quickalert (SK 4/2)
In the zone types shown below, “Burglary” is used as an example. The first letter that will
be transmitted for each zone type is shown below:
H = Holdup
F = Fire
P = Panic
B = Burglary
T = Tamper
S = Sprinkler (formerly Gas)
W = Water
K = Heat
Z = Cold
U = Undefined
*M or Q = Emergency
(Burglary) Alarm 1 - 80 (B)A# Zone in alarm
(Burglary) Trouble 1 - 80 (B)T# Loop faulted or RF transmitter failed
(Burglary) Bypass 1 - 80 (B)B# Zone bypassed
(Burglary) Unbypass 1 - 80 (B)U# Zone unbypassed
(Burglary) Supervisory 1 - 80 (B)S# RF transmitter low battery
(Burglary) Restore 1 - 80 (B)R# Restore to normal, due to:
Alarm Reset/Shutdown
Loop fault repaired
Transmitter battery replaced
Holdup alarm 0 HA0 Duress
Fire alarm 81 FA81 Fire panic key
* (Emergency) Alarm 82 * MA82 or
QA 82
Aux key
(Panic) Alarm 83 PA83 Police panic key
Temperature 0 - 255F ch. 1 DA 0-255 Analog temperature sensor has reached its
preset limit. The number following “tempera-
ture” is the actual temperature at time of
reporting.
Air flow ch. 2 DB 0 - 255 Air is moving past the air flow sensor.
Humidity 10 - 90 prct ch. #3 DI 10 - 90 Analog humidity sensor has reached its preset
limit. The number following “humidity” is the
actual humidity at the time of reporting.
Fluid level 0 - 180 in. ch. #4 DM 0 -
180
Analog fluid level sensor has reached its pre-
set limit. The number following “fluid level” is
the actual level (in inches of water) at the
time of reporting.
9000 Printer Code Status of 4720
* Note: The 4720 sends “MA”; the Model 4724-2 and the Model 4734-2 send “QA”.
