the lling process, all tapping points on the drinking water installation must be
opened one after another, starting with the furthest away, until the dyed disin
-
fection solution emerges at the respective tapping point. If the tapping point is
in a dark environment it is helpful to hold a white background (e.g. a sheet of
paper) behind the outlet in order to be able to see the disinfection solution
better.
The supply to the disinfection unit before REMS Multi-Push and the drain to
the drinking water installation must be shut off at the end of the disinfection
process. Then the bottle (21) must be removed slowly so that excess pressure
can escape.
After 24 hours exposure (recommendation of the German Central Association
for Sanitary, Heating and Air Conditioning (ZVSHK) and recommendation of
the German Association of the Gas and Water Industry (DVGW), the disinfec
-
tion solution must be ushed out of the drinking water installation with REMS
Multi-Push. To do this, all tapping points must be opened again one after another,
starting with the nearest, until there is no longer any trace of the dyed disinfec
-
tion solution.
Additionally, peroxide test strips can be used if necessary to check the concen
-
tration (accessories, see 1.2. Article numbers).
NOTICE
Hoses used for disinfection/cleaning should no longer be used for pressure
testing with water and for ushing drinking water pipes.
3.3. Testingdrinkingwaterinstallationswithcompressedairprogram
WARNING
For Germany the information leaet "Leak Tests of Drinking Water Installations
with Compressed Air, Inert Gas or Water" (January 2011) of the German Central
Association for Sanitary, Heating and Air Conditioning (ZVSHK) denes the
following for the national regulations under "3.1 General":
"Due to the compressibility of gases, the rules for the prevention of accidents
"Working on Gas Systems" and the "Technical Rules for Gas Installations
DVGW-TRGI" must be observed for physical and safety reasons when
conducting pressure tests with air Therefore, the test pressures have been
dened as maximum 0.3 MPa/3 bar/43.5 psi, the same as for load and leak
tests for gas pipes, in agreement with the responsible industrial liability
insurance association and based on these rules. The national regulations are
thereby fullled.“
 Therespectivenationalsafetyprovisions,rulesandregulationsvalidfor
theapplicationsitemustbeconsideredandobserved.
Before conducting a test with compressed air, it must be assessed whether the
installation to be tested will withstand the preset / selected test pressure "p
refer".
Section 6. of EN 806-4:2010 denes among other things that: "Installations
inside buildings must be subjected to pressure testing. This can be done either
with water or, if national regulations allow, oil-free, clean air with low pressure
or inert gases may be used. The possible risk from high gas or air pressure in
the system must be considered." However, apart from this note, the standard
EN 806-4:2010 contains no test criteria whatsoever for testing with compressed
air.
The tests described below and the defaults stored in the REMS Multi-Push
correspond to the information leaet "Leak tests of drinking water installations
with compressed air, inert gas or water" (January 2011) of the German Central
Association for Sanitary, Heating and Air Conditioning (ZVSHK). Future changes
to this information leaet or the respective valid provisions, rules and regulations
for the application site must be considered and changed test criteria (test
sequences, pressures and times) must be corrected in the defaults.
The programs can be aborted at any time with the Esc button (10). Then all
the valves open and the pressure in the installation is released. The tests are
saved but "Cancel" is shown in the le.
3.3.1. Leak test with compressed air (ZVSHK)
Test pressure 150 hPa (150 mbar)
Program sequence ↑ ↓ (8):
1. Test \ Enter
2. Test with compressed air \ Enter
3. Leak test \ Enter
4. Check reference test pressure default (p refer) and change if necessary
(11) \ ↓
5. Check stabilisation default (t stabi) and change if necessary (11) \ ↓
6. Check test time default (t test) and change if necessary (11) \ ↓
7. Actual test pressure (p actual) is adjusted to reference test pressure (p
refer) \ Enter
8. Stabilisation/wait time (t stabi) running, actual test pressure (p actual) is
changed to reference test pressure (p refer) on expiring. The stabilisation/
wait time can be ended prematurely with Enter, the test time (t test) then
begins immediately (\ Esc = cancel).
9. Display screen: Reference test pressure (p refer), actual test pressure (p
actual), differential test pressure (p diff), test time (t test) \ Enter
10. Esc >> Start menu \ Memory Manager, data transfer >> 3.6
3.3.2. Load test with compressed air ≤ DN 50 (ZVSHK)
Test pressure 0.3 MPa (3 bar)
Program sequence ↑ ↓ (8):
1. Test \ Enter
2. Test with compressed air \ Enter
3. Load test ≤ DN 50 \ Enter
See leak test 4. to 10. for further procedure
3.3.3. Load test with compressed air > DN 50 (ZVSHK)
Test pressure 0.1 MPa (1 bar)
Program sequence ↑ ↓ (8):
1. Test \ Enter
2. Test with compressed air \ Enter
3. Load test > DN 50 \ Enter
See leak test 4. to 10. for further procedure
3.4. Testingdrinkingwaterinstallationswithwaterprograms(REMSMulti-Push
SLW)
Section 6.1 of EN 806-4:2010 offers 3 test methods A, B, C for hydrostatic
pressure testing depending on the material and size of the installed pipes. The
test methods differ in different test sequences, pressures and times.
For Germany, the information leaet "Leak Tests of Drinking Water Installations
with Compressed Air, Inert Gas or Water" (January 2011) of the German Central
Association for Sanitary, Heating and Air Conditioning (ZVSHK), the following
is dened with regard to the test methods A, B, C for pressure testing with water
offered in section 6.1 of EN 806-4:2010: "For reasons of practicability on the
building site, a modied method based on practical tests which can be used
for all materials and combinations of materials was chosen. The test time has
been extended in relation to the time specied in the standard to allow even
the slightest leaks to be detected. Test method B in accordance with DIN EN
806-4 is the basis for conducting the leak test with water for all materials." The
following is dened:
Leak testing with water can be conducted when
● changing of the water can be ensured at regular intervals, after seven days
at the latest, from the time of the leak test to commissioning of the drinking
water installation. Additionally when
● it is ensured that the house or building water connection is ushed and
therefore released for connection and operation,
● the pipe system is lled using totally hygienic components,
● the system remains full from the leak test to commissioning and partial
lling can be avoided.
WARNING
The hydro-pneumatic water pump installed additionally in the REMS Multi-Push
SLW for these tests is fed by the built-in compressor of the REMS Multi-Push.
The hydro-pneumatic pump generates a water pressure of max. 1.8 MPa/
18 bar/261 psi. Before conducting one of the tests with water A, B, C, it must
be assessed whether the installation to be tested will withstand the preset/
selected test pressure "p refer".
CAUTION
Before disconnecting the high-pressure hose (26) from the pressure test with
water drain (25) or from the drinking water installation, make sure that the
pressure has been totally relieved.
The programs can be aborted at any time with the Esc button (10). Then all
the valves open and the pressure in the installation is released. The tests are
saved but "Cancel" is shown in the le.
3.4.1. Pressure test with water, test method A (EN 806-4:2010, 6.1.3.2)
Program sequence ↑ ↓ (8):
1. Test \ Enter
2. Test with water \ Enter
3. Test with water A \ Enter
4. Check reference test pressure default (p refer) and change if necessary
(11) \ ↓
5. Check stabilisation default (t stabi) and change if necessary (11) \ ↓
6. Check test time default (t test) and change if necessary (11) \ ↓
7. Actual test pressure (p actual) is adjusted to reference test pressure (p
refer) \ Enter
8. Stabilisation/wait time (t stabi) running, actual test pressure (p actual) is
changed to reference test pressure (p refer) on expiring. The stabilisation/
wait time can be ended prematurely with Enter, the test time (t test) begins
immediately (\ Esc = cancel).
9. Display screen: Reference test pressure (p refer), actual test pressure (p
actual), differential test pressure (p diff), test time (t test) \ Enter
10. Esc >> Start menu \ Memory Manager, data transfer >> 3.6
3.4.2. Pressure test with water, testmethodΔ>10K(B/1): Temperature
compensation (EN 806-4:2010, 6.1.3.3)
Program sequence ↑ ↓ (8):
1. Test \ Enter
2. Test with water \ Enter
3. Test with water B \ Enter
4. Test Δ>10K(B/1) \ Enter
5. Check reference test pressure default (p refer) and change if necessary
(11) \ ↓
6. Check stabilisation default (t stabi) and change if necessary (11) \ ↓
7. Check test time default (t test) and change if necessary (11) \ ↓
