73
TIP: To prevent retracting at the end of the cycle, use
an R26=0 input.
R03=c c= When this input is used, enter the number of cutting
edges on the tool. The spindle speed is then
automatically adjusted to enable errors on each cutting
edge to be checked.
The cycle time using this method is significantly
increased, unless the default 0.1 mm/rev (0.004 in/rev)
is increased using the R09=f input.
Default value: The spindle speed is set by either the
R19=s input, or by the default value defined in the
setting subroutine L9760 when no R19=s input is used.
R03=1. The spindle speed is automatically adjusted for a cutter
with a single cutting-edge to ensure it is properly
checked.
This is also suitable for multiple-tooth cutters, when
only the maximum/minimum cutting-edge profile needs
to be checked. The cycle time will be faster than
checking each individual cutting edge.
R06=k k= The tolerance value that defines when the cutter profile
is out of limits.
Default value: 0.025 mm (0.001 in)
R09=f f= Feedrate specified as feed/rev for profile checking.
Default value: 0.1 mm/rev (0.004 in/rev)
Cutter radius and linear profile checking
