75
R17=q q= Included angle of the cutter radius.
Range: ³ 0° £ 90°
R18=r r= The cutter radius value.
R24=x x= Linear distance moved tangentially past the cutter
radius profile (see the figures on page 71).
Range: ³ 0
R25=y y= Radial distance to the cutter radius centre.
Range: ³ 0
Additional subroutine inputs for linear profile checking
only
R11=h h= The height to the first profile checking position (see the
figures on page 71).
This is the height above the tool length offset position.
Range: ³ 0
Default value: R06=k value.
R17=q q= Angle of the linear profile (see the figures on page 71).
Range: ³ 0° £ 90°
R24=x x= Distance along the surface for profile checking (see the
figures on page 71).
Range: ³ 0
R25=y y= Radial position to the first profile checking position.
Range: ³ 0
Cutter radius and linear profile checking
