Reolink RLN8-410 User Manual

Reolink PoE NVR
User Manual
2
1. NVR Introduction
Device Overview
RLN8-410/RLN16-410
Reolink has 16-channe PoE NVR RLN16-410 and 8-channel PoE NVR RLN8-410. Add
cameras to the PoE NVR, you are able to customize your own security systems.
Reolink PoE IP security camera systems feature plug and play, 12MP,4K Ultra HD,
or 5MP/4MP, which are easy to set up and simple to use, for DIY enthusiasts and
beginners. Features of our NVR video system also include excellent night vision,
24/7 continuous recording, local & remote access, and more.
RLN8-410
Power Switch
eSATA
RJ45
Power lnput
Audio Out
USB Port
HDMI Port
VGA Port
Network

Reolink RLN8-410 Specifications

General

Video codecs	H.264
Display modes	Live view
Number of users	20 user(s)
Maximum resolution	3840 x 2160 pixels
Video input channels	8 channels
Supported resolutions	3840x2160, 1920x1080, 1440x900, 1280x1024, 1280x800, 1280x720, 1024x768
On/off switch	Yes
Product color	Black
Audio RCA outputs	1
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
Supported network protocols	HTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
Power over Ethernet (PoE) ports quantity	8
Wi-Fi	No
HDD capacity	2000 GB
HDD interface	SATA, SATA II, SATA III
Maximum storage capacity	8 TB
Output current	2 A
Output voltage	48 V
Power consumption (max)	25 W
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	230 mm
Width	260 mm
Height	41 mm
Weight	1200 g
