Respironics BiPAP Focus - Recommended Tools and Test Equipment

Chapter 1
1-2 BiPAP® Focus™ Ventilator Service Manual © Respironics, Inc. REF 1029568 Rev A
Introduction and Intended Use
Recommended Tools
and Test Equipment
Table 1-1 lists the recommended tools, test equipment, and materials required
to service and maintain the BiPAP Focus Ventilator.
Table 1-1: Recommended Test Equipment, Tools, and Materials
Description Manufacturer and Model
Test Equipment
Digital multimeter (DMM) accurate to three decimal
places
Local Supplier
Electrical safety analyzer Dale LT 5440 or equivalent
Pneumatic calibration analyzer capable of measuring
low pressure (cmH
2
O), flow rate (LPM), and volume
(liters)
Respironics P/N 1012598 or equivalent
Ventilator Accessories
Connector, plastic, 22mm OD Respironics P/N 1006242 or equivalent
Connector, 22-mm (quantity 2) Respironics P/N or equivalent
Flow Control Valve Respironics P/N 1006120
Pressure test adapter Respironics P/N 312710
Tee, plastic with silicone rubber coupling Respironics P/N C06260 or equivalent
Tee silicone (quantity 2) Respironics P/N 1006243 or equivalent
Hand Tools and Materials
Pliers Local supplier
#1 Phillips head screwdriver Local supplier
#2 flat head screwdriver Local supplier
#2 Phillips head screwdriver Local supplier
Cleaning Cloth Local supplier
Isopropyl Alcohol Local supplier
Metric hex key set (rounded ends), 1.5 to 4 mm Local supplier
Mild detergent or antiseptic wipes Local supplier
Needle nose pliers Local supplier
BiPAP Focus Communications Cable Kit
(USB & DB9)
Respironics P/N 1030010
PC or laptop (required for downloading software) Required: Windows XP operating
systems, serial comm port, and USB
port
Pen size flat head screwdriver Local supplier
Pen size Phillips head screwdriver Local supplier
Test lung, hard sided Respironics P/N 1021671 or local
supplier
Torque driver capable of 1 to 25 in.-lbs (N-m) Local supplier
