Chapter 7
Performance Verification
REF 1029568 Rev A BiPAP® Focus™ Ventilator Service Manual © Respironics, Inc. 7-9
4. Remove the bacteria filter from the ventilator if it is connected.
5. Ensure that one end of the 6' Smooth-bor tubing is attached to the
Druck DPI-260 O
2
port and the other end connected to the ventilator.
6. Ensure that the AC power cord is connected to the MFTS.
7. Ensure the MFTS has been running for a minimum of 1 hour before
being using to calibrate units.
MFTS software setup
1. Double-click the MFTS icon located on the PC's desktop to load
software.
2. Skip the Name and Password dialog box by clicking OK.
Figure 7-5: MFTS Name and Password
3. Click the Open button in the top left-hand corner.
4. Select file name BiPAP Focus Production Post Test and press the
Enter key.
