Chapter 7
7-2 BiPAP® Focus™ Ventilator Service Manual © Respironics, Inc. REF 1029568 Rev A
Performance Verification
Required Test
Equipment
Table 7-3 summarizes the test equipment required, and Table 7-4 summarizes
the service accessories required for the performance verification. Check the
calibration status of all test equipment before use.
Required Test Equipment for Performance Verification
Description Recommended Manufacturer/Model
Digital multimeter (DMM) and frequency counter
accurate to three decimal places
Local supplier
Electrical safety analyzer Dale LT 5440 or equivalent
Pneumatic calibration analyzer(s) capable of
measuring low pressure (cmH2O), flow rate (LPM),
volume (Liters BTPS), and respiratory rate
Respironics P/N 1012598 or equivalent
Utility Software
Calibration and testing of the BiPAP Focus requires
the use of Respironics Utility Software
Log on to
http:// servicesoftware.respironics.com
and download the Utility Software onto
your PC.
Table 7-3: Required Test Equipment for Performance Verification
Required Service Accessories for Performance Verification
Description Part Number
Adapters, oxygen enrichment
(quantity 2)
Respironics P/N 312710 or equivalent
Bacteria filter, reusable inspiratory Respironics P/N 1003847
Connector, 22-mm (quantity 2) Respironics P/N 1006242 or equivalent
Coupling, silicone (quantity 2) Respironics P/N C06348
Pressure test adapter Respironics P/N 312710
Reusable Patient Tubing Circuit Respironics P/N C06122
Test orifice, RP20 Michigan Instruments or equivalent
0.25" Test Orifice Respironics P/N 332353
Silicone cork Respironics P/N 1001735
BiPAP Focus Communications Cable Kit
(USB & DB9)
Respironics P/N 1030010
Tee, plastic w/silicone coupling Respironics P/N C06260
Tubing, silicone, 3/16-in. ID x 6.5 ft.
PAP
Respironics P/N C06686
Table 7-4: Required Service Accessories for Performance Verification
