ASMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 31
Hardware Revision:
Displays the Receive Systems Module’s Hardware Revision.
Module Serial Number:
Displays the Receive Systems Module’s Module Serial Number.
RxA to Rx-Output Gain:
Displays the configured gain in the signal path from the RxA Input to the Rx Output to the ASM.
RxB to Rx-Output Gain:
Displays the configured gain in the signal path from the RxB Input to the Rx Output to the ASM.
Antenna RxE to Rx-Output Gain:
Displays the configured gain in the signal path from the RxE Input to the Rx Output to the ASM.
RxA IN to RxA OUT On/Off:
Displays the configured state of this RF path. “ON” is a nett gain of 0dB, “OFF” is a maximum attenuation in this path (>25dB).
RxB IN to RxB OUT On/Off:
Displays the configured state of this RF path. “ON” is a nett gain of 0dB, “OFF” is a maximum attenuation in this path (>25dB).
Status:
Alarm Status:
Indicates the current status of the RSM’s alarms.
RxA Peak Level:
Displays the highest level signal measured on the RxA input. See Reset Peak Levels (below)
RxA Current Level:
Displays the last signal measured on the RxA input.
RxB Peak Level:
Displays the highest level signal measured on the RxB input. See Reset Peak Levels (below)
RxB Current Level:
Displays the last signal measured on the RxB input.
Antenna (RxE) Peak Level:
Displays the highest level signal measured on the RxE input. See Reset Peak Levels (below)
Antenna (RxE) Current Level:
Displays the last signal measured on the RxE input.
Power Supply:
Displays the current alarm state of the RSM’s power supply.
