1.Detailed Descriptions
9
No.
Description
No.
Description
1
Stack height lever HP sensor (S18)
5
Controller board (PCB1)
2
Paper surface sensor (S17)
6
Cooling fan motor (FAN1)
3
Stack height lever motor (M6)
7
Paper exit full sensor (S8)
4
Cover open/closed switch (SW1)
8
Tray lift motor (M15)
