Ricoh SR3300 - Stapler Unit

2.Replacement and Adjustment
23
Stapler Unit
Stapler Unit
1. Remove the rear cover. (Rear Cover)
2. Disconnect the connector and release the clamps ( ×1, ×2).
3. Turn the finisher [A] over.
4. Remove the screws securing the stapler unit [A] ( ×5).
