Ricoh SR3300 - Door Switch (SW1)

2.Replacement and Adjustment
29
3. Remove the sub-scan registration sensor [A] together with the bracket ( ×1).
4. Remove the sub-scan registration sensor (S2) [A].
Door Switch (SW1)
1. Remove the rear cover (Rear Cover).
2. Remove the screw ( ×1).
