Ricoh SR3300 - Paper Exit Pressure HP Sensor (S8)

2.Replacement and Adjustment
31
2. Remove the screw securing the bracket.
3. Remove the paper exit sensor (S3) [A] ( ×1).
Paper Exit Pressure HP Sensor (S8)
1. Remove the paper exit cover (Paper Exit Cover).
2. Remove the screw and release the clamp.
