Ricoh SR3300 - Shift HP Sensor (S7); Paper Exit Sensor (S3)

2.Replacement and Adjustment
30
3. Remove the door switch (SW1) [A] ( ×1).
Shift HP Sensor (S7)
1. Remove the finisher front cover (Finisher Front Cover).
2. Remove the shift HP sensor [A] together with the bracket ( ×1, ×1).
3. Remove the shift HP sensor (S7) [A] ( ×1).
Paper Exit Sensor (S3)
1. Remove the finisher upper cover (Finisher Upper Cover).
