Sloped building-structure
• If the building structure is sloped Ridder recommends to put the tube motor and guiding system
at the highest posion. This makes sure that water can ow away from the tube motor along the
roller screen when it is winded up.
Assembly order
• In the manual an assembly order is given. A dierent order can be used, but you must obey the
guidelines in this manual.
ALTERNATIVES
Replacement - Guiding unit: P20 to VK10 (tube motor 550032/550039)
• The replacement (VK10) for the P20 guiding unit.
• There is a special guiding unit for the two installaon sides of the roller screen.
Tube motor 550037: Adapter VK10 to P20
• The 550037 is a tube motor (VK10) with an adapter set 550411. The head of the tube motor is
changed to P20.
• The tube motor is aached to the guiding unit (P20) with hex socket-screws M4 and a locking
plate.
• There is a special guiding unit for the two installaon sides of the roller screen.
550032
550039
P20
4.2.3
VK10
4.2.4
P20
550037
550411
