4.3 Installaon guiding prole and guiding unit
Prepare the guiding prole.
1. Cut the guiding prole (3) to the correct length l1. Refer to illustraon 4.3.1. The guiding prole
(3) is supplied in standard lengths. The necessary length l1 is usually equal to the distance
between the purlins or between the purlin and foundaon. Refer to illustraon 4.3.3. A small
number of millimeters shorter than l1 is also permied.
2. Drill the holes of ø 6.5mm (4x). Refer to illustraon 4.3.1.
3. Put the guiding unit (2) onto the guiding prole (3). Refer to illustraon 4.3.2.
Put the guiding prole and guiding unit in posion.
4. Put the guiding prole (3) with guiding unit (2) between:
- The purlins (A) and (D)
OR
- The purlin (A) and the foundaon (C).
Use 4 bolts M6 (11) and self-locking nuts (12) to aach the mounng brackets (4) to the guiding
prole (3).
Note: It is recommended to ghten the nuts (temporarily) with your hand.
Refer to illustraon 4.3.3.
5. Put the guiding prole (3) with guiding unit (2) and mounng brackets (4):
- Aligned with the purlin (A)
- At the distance of 41 mm between the guiding prole (3) and post (B).
Refer to illustraon 4.3.3.
6. Find (in the width of the purlin) the posion of the guiding prole (3) where the guiding unit (2)
can move to the highest point. The highest point possible of the guiding unit (2) is related to the
width of the purlin (A).
Refer to illustraon 4.3.4.
