2.3 Residual risks
Automated controls
The Ridder RB50Eᵖˡᵘˢ tube motors are generally used in automac controlled roller-screen systems.
Persons who do work or stay near the roller-screen system must know about that. If persons or their
cloths touch the roller-screen system when it winds up, it could have serious consequences.
Torque guard
The RB50Eᵖˡᵘˢ tube motor has a torque guard. The funcon is to minimize the risk of injury to
persons, damage to the system or damage to the tube motor. Because of the forces in the systems
(in which the tube motor is installed), Ridder cannot be sure that there will be no injury to persons
or damage to the system.
2.4 Symbols and abbreviaons
This secon tells about used symbols and abbreviaons in this manual. The table that follows gives
the descripons.
Symbol Description Symbol Description
ACS Automac control system N Neutral wire
CB Control box with switch components P20
Journal with 2 at sides at a
distance of 20 mm (parallel)
EM, M Electric motor, Motor P71, P72 Automac control contacts (ACS)
FCP Female connecon PE Protecve earth
F11 Fuse RB Tube Motor
I
Current charging rate at full load in
Amperes (A)
SS
System switch (put near the tube
motor)
kb
Maximal cycle in minutes (min) (kb =
KurzBetrieb/ Short operaon)
S21
System switch (to stop the tube
motor)
L1 Voltage source, Phase-1 S111 Manual switch (MC)
M Drive torque in Newton metres (Nm)
U
Nominal mains voltage / supply
voltage in Volts (V)
MCP Male connecon
MPCB Motor Protecon Circuit Breaker
U1, V1, W1 Motor connecon
n
Speed of revoluons in revoluons
per minute (/min)
VK10 Journal square 10x10 mm
Persons can be in danger of life if they touch a roller-screen system
that turns.
Ridder Drive Systems
T +31 (0)341 416 854 F +31 (0)341 416 611 I www.ridder.com
5
