Ridder RB50EPLUS - INSTALL INSTRUCTIONS

3.5 Idencaon
This product manual is only applicable to:
• Ridder RB50Eᵖˡᵘˢ tube motors (2016)
• Serial numbers from 200.900.000
• Item numbers: 550032
550037
550039.
Idencaon is possible from the scker on the locaon shown. Refer
to the explanaon that follows on how to read the informaon. For
more informaon on item numbers and models refer to the Ridder
catalogue or website www.ridder.com.
4. INSTALL INSTRUCTIONS
4.1 Special tools and equipment
Ê
EXAMPLE
B50: Diameter of the tube motor in mm
VK10: Journal dimensions in mm (10x10)
Alternaves: P20 - width in mm
50: Mains frequency 50 Hz
230: Mains voltage 230 V
3.5: Number of revoluons drive sha at 50 Hz
E+: Tube motor with electronic limit-switch
50: Torque RB tube motor in Nm
RB: General designaon Ridder tube motors
L772: Length (l) of the tube motor in mm
Alternaves: 846 mm
Make sure that the correct equipment and tools are used.
During mechanical installaon an adjusng switch can be used, if
necessary, to operate the tube motor.
§7.2 gives more informaon about the adjusng switch.
