Machine Mounting and
Transporting
WARNING
To prevent serious injury, proper mounting of the
Threading Machine is required. The following pro-
cedures should be followed:
Mounting Machine To Stand
1. The machine is designed to mount on the three uni-
versal stands listed below.
2. Parts diagram and parts list for the stands are in-
cluded in the 1224 Parts List.
3. Assemble stand with “inside” decals located towards
the inside of the stand (Figure 3).
4. Insert stand stop tabs into bottom of the legs as
shown in the detail drawing. Insert the four spacers
between the legs. Use the four (4)
3
/
8
″ – 16 x 4″ hex
bolts to secure the legs to the cross-member. Adjust
the two halves of the stand stop to the proper distance
20.25
43.69
18.42
15.50
28.84
11.92
Figure 2 – 1224 Machine Dimensions
Machine Stands
Model No. Description
100 Universal Leg & Tray Stand
150 Universal Wheel & Tray Stand
200 Universal Wheel & Cabinet Stand
Special Notes
Self-opening die head
Self-opening die head
Quick-opening die head
Self-opening die head
Self-opening die head
Quick-opening die head
Alloy or high speed dies, UNC or UNF
BSW or BSF right hand or left hand
Alloy or high speed dies, UNC or UNF
BSW or BSF right hand or left hand
Die Head
Model No.
711 NPT
714 NPT
713 NPT
911 BSPT
914 BSPT
913 BSPT
541
542
Capacity
Pipe Bolt
1
/
4
″ - 2″
1
/
4
″ - 2″
2
1
/
2
″ - 4″
1
/
4
″ - 2″
1
/
4
″ - 2″
1
/
4
″ - 2″
2
1
/
2
″ - 4″
1
/
4
″ - 2″
1
/
4
″ - 1″
1
1
/
8
″ - 2″
Sets of Dies
Pipe Bolt
3 16 UNC
14 UNF
1
3
3 16 BSW
1
3
10 UNC
6 UNC
4 UNF
Threads
R.H L.H.
X
X
X
X
X
X
XX
XX
American National Series (High Speed) Dies (8 T.P.I. 1
1
/
8
″ - 2
1
/
2
″) (12 T.P.I.
1
/
2
″ - 2
1
/
2
″), and (16 T.P.I.
13
/
16
″ - 2
1
/
2
″)
General purpose Acme and Metric dies for 541 and 542 bolt die heads available on request.
Die Heads and Dies
