RIGOL 2 Command System
2-210 MSO2000A/DS2000A Programming Guide
:REFerence:SAVe
Syntax
:REFerence:SAVe
Description
Store the waveform (screen region) of the specified signal source to the internal memory as the reference
waveform of the current reference channel and display the waveform on the screen.
Explanation
This operation can only store the reference waveform in the volatile memory and the waveform will be
cleared at power-off.
:REFerence:SOURce
Syntax
:REFerence:SOURce <source>
:REFerence:SOURce?
Description
Set or query the reference source of the current reference channel.
Parameter
Name Type Range Default
<source> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|
D12|D13|D14|D15|CHANnel1|CHANnel2|MATH}
CHANnel1
Explanation
 Only channels currently turned on can be selected as the reference source of the current channel.
 You can use the
:REFerence<n>:CURRent command to selected the current channel.
Return Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14, D15, CHAN1,
CHAN2 or MATH.
