RIGOL 2 Command System
2-74 MSO2000A/DS2000A Programming Guide
:CURSor Commands
 :CURSor:MODE
 :CURSor:MANual
 :CURSor:TRACk
:CURSor:MODE
Syntax
:CURSor:MODE <mode>
:CURSor:MODE?
Description
Set or query the cursor measurement mode.
Parameter
Name Type Range Default
<mode> Discrete {OFF|MANual|TRACk|AUTO|XY} OFF
Explanation
OFF: disable the cursor measurement.
MANual: enable the manual cursor measurement.
TRACk: enable the track cursor measurement.
AUTO: enable the auto cursor measurement.
XY: enable the X-Y cursor measurement. This mode is only valid when the horizontal time base mode is
X-Y.
Return Format
The query returns OFF, MAN, TRAC, AUTO or XY.
