Rigol 2000 Series Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-277
:TRIGger:EDGe
 :TRIGger:EDGe:LEVel
 :TRIGger:EDGe:SLOPe
 :TRIGger:EDGe:SOURce
:TRIGger:EDGe:LEVel
Syntax
:TRIGger:EDGe:LEVel <level>
:TRIGger:EDGe:LEVel?
Description
Set or query the trigger level in edge trigger. The unit is the same as the current amplitude unit.
Parameter
Name Type Range Default
<level> Real
When the trigger source is CHANnel1 or CHANnel2:
-5×VerticalScale–OFFSet to +5×VerticalScale–OFFSet
When the trigger source is any of D0-D15: -20V to 20V
When the trigger source is EXT: -4V to 4V
When the trigger source is ACLine: do not need to set this parameter
0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Return Format
The query returns the trigger level in scientific notation.
