RIGOL 2 Command System
2-60 MSO2000A/DS2000A Programming Guide
:CALCulate:LOGic:ATHReshold
:CALCulate:LOGic:BTHReshold
Syntax
:CALCulate:LOGic:ATHReshold <thre>
:CALCulate:LOGic:ATHReshold?
:CALCulate:LOGic:BTHReshold <thre>
:CALCulate:LOGic:BTHReshold?
Description
Set or query the threshold of signal source A or B of logic operation.
Parameter
Name Type Range Default
<thre> Real -4×VerticalScale-OFFSet to 4×VerticalScale-OFFSet 0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Explanation
 This command is only available when signal source A or B is CH1 or CH2.
 If the current logic operation type is NOT, you only need to set the threshold of signal source A.
Return Format
The query returns the threshold in scientific notation.
