RIGOL
© 2008 RIGOL Technologies, Inc.
User‟s Guide for Logic Signal Output Module
1-2
Ports of the Module
When you get a new DG3000 Logic Signal Output Module, first be familiar with the
ports and markings on it. There are three main ports: port connected to DG3000, a
digital logic output and an analog logic output, as shown in Figure 1-1.
Figure 1-1 Port instruction of the module
Indicator light of the digital logic output
Indicator light of the digital logic output
Indicator light of the analog logic output
Connect to DG3000
