User‟s Guide for Logic Signal Output Module
Logic Signal Output Module at a Glance
RIGOL company‟s Logic Signal Output Module which has 16-channel data outputs
and 2-channel clock outputs, making DG3000 series practical and meaningful Mixed
Signal Generator (MSG). The logic outputs can be configured according to user‟s
needs for specific timing of digital signals. The outputs can be used as logic circuit
signal sources, for testing and analysis of the logic circuit designs. General digital
signal protocols can be constructed easily; in conjunction with the analog channels,
real life mixed signals can be produced.
The Logic Signal Output Module has the following function features:
Module operation can be turned “ON” or “OFF”;
Two operation modes: “Depend” and “Independ”;
Two trigger modes: Auto, Burst;
Four protocols: RS232、I
2
C、SPI、PO;
User-defined protocol output based on PO protocol;
A variety of code pattern outputs: All „0‟, All „1‟, „01‟ turn, IEEE standard
pseudorandom sequence;
Online data editing of protocols;
Arbitrary output rate in the “Depend” work mode;
User-defined channels output, including data and clock lines (choose from
16+2);
Digital channel and analog channel outputs and respectively setting of
channels output or not;
Provide TTL, LVTTL, CMOS, LVCMOS and user-defined output voltage;
Remote configuration;
Embedded help.
