User‟s Guide for Logic Signal Output Module
1-8
User Interface
DG3000 Series Function/Arbitrary Waveform Generators provide users clear and
easy-to-use graphical displays for: Communication Protocol Interface, and Data
Editing Interface.
Communication protocol interface allows users to configure the system:
 Select digital communication protocols
 Select multifarious code patterns or user-defined patterns
 Set the data output length
 Select data transmission rate or user-defined rate output
 Set trigger mode and trigger level
 Configure output channels with various signal line.
Data Editing Interface allows users to:
 Edit data in hexadecimal or binary form
 Store the waveform data in non-volatile memory,
 Recall and edit stored data.
