Chapter 4 Prompt Message & Troubleshooting
Prompt Message
Common Prompt Message
1. Digital module is installed, Please wait, press help key to reset。
Power-on prompting message 1. It prompts users that digital module has been
connected.
2. Need Help? Press and hold down any key. Selected interface is USB.
Mobile disk is moved. Not detect a digital module. Digital output will
be closed.
Power-on prompting message 2. It prompts users that the setting has been
restored; users can operate the instrument normally. When power-on, the
system detects the current setting and USB interface has chosen; prompts not
USB device is detected; and prompt that digital module has not connected.
3. Need Help? Press and hold down any key. Selected interface is USB.
Mobile disk is moved. Detected a digital module.
Power-on prompting message 2. It prompts users that the setting has been
restored; users can operate the instrument normally. When power-on, the
system detects the current setting and USB interface has chosen; prompts not
USB device is detected; and prompt that digital module has been connected.
4. The function is optional. Please connecting digital module to fulfill the
performance. Getting more help, please visit www.rigol.com.
If digital module has not been connected, press Utility Output Setup
Digit-Modu, when trying to choose “Power-On”, this message will appear to
prompt users digital module should be connected first.
5. Press “Arb” to complete change of configuration. Or switch to
arbitrary wave mode if not change any parameter.
Connect digital module, press Arb Edit Digital W, this message will appear,
