Rigol DG3000 Series

RIGOL
© 2008 RIGOL Technologies, Inc.
User‟s Guide for Logic Signal Output Module
1-4
The digital logic output port is shown below in Figure 1-4. The outputs are located
at the two sides of the module. The module provides 16 digital channels (D
0
～D
15
)
+ 2 clock output channels (DCLK0, DCLK1).
Figure 1-4 Ports instruction of the digital logic output
D
8
D
9
D
10
D
11
D
12
D
13
D
14
D
15
DCLK1
D
8
D
8
DCLK0 D
7
D
6
D
5
D
4
D
3
D
2
D
1
D
0
D
8
D
8
