FSK Modulation
Modulating Source Internal
FSK Rate 100 Hz
Hop Frequency 10 kHz
FSK Polarity Positive
PSK Modulation
Modulating Source Internal
PSK Rate 100 Hz
PSK Phase 180°
PSK Polarity Positive
IQ Modulation
Modulating Source Internal
Baud Rate 9600 bps
Code Pattern PN9
Mapping 4QAM
Sweep
Sweep Type Linear
Steps 2
Sweep Period 1 s
Start Hold 0 s
End Hold 0 s
Return Time 0 s
Start Frequency 100 Hz
End Frequency 1 kHz
Enter Frequency 550 Hz
Frequency Span 900 Hz
Mark Frequency OFF
Trigger Source Internal
Trigger Output OFF
Trigger Input Leading
Burst
Burst Type N Cycle
