Appendix C: Specifications of Digital Module
Unless otherwise noted, all the specifications are applicable to the digital modules of
DG5000 series function/arbitrary waveform generator. All the specifications can be
guaranteed if the following two conditions are met.
 The generator has been working continuously for 30 minutes at specified
temperature.
 Open the system function menu and execute “Test Calibration” if the operating
temperature is equal to or more than 5℃.
Common Specifications
Digital Voltage Range
1.4～4.2V (Typical value and user-defined value) (except RS232)
Trigger Mode Auto trigger and burst trigger
Code Pattern ALL_0, ALL_1, 01, PRBS, User
User Space 256k Bytes in-line editing, 2M Bytes output (PC editing)
Parameters and Specifications relating to PO Protocol
Analog Voltage Range
1.4～9.4V
Clock (CLK) Line C0 and C1 (selectable)
Clock Phase 0
0
, 90
0
, 180
0
, 270
0
(adjustable)
Data Line
D0～D15 (selectable)
Transmission Rate
1bps～100Mbps (adjustable)
Output Data Range
1Byte～128k Bytes (selectable)
Mask Channel Setting
None, D0～D15 (selectable)
Tri-state Channel Setting
None, D0～D15 (selectable)
Parameters and Specifications relating to IIC Protocol
Analog Voltage Range
1.4～9.4V
Bit Order MSB
Clock (CLK) Line
D0～D15 (selectable)
Data Line
D0～D15 (selectable)
Transmission Rate
1bps～15Mbps (adjustable)
Output Data Range
1Byte～10k Bytes (selectable)
Output Address (selectable) None or 7bits address
Operation Mode When selecting address output, select read or write mode
Parameters and Specifications relating to SPI Protocol
